ADVANCE.FAST.EFFICIENT

FEATURES

Housing Assembly

Housing transmits the torque generated by the main motor to the blade assembly. It also changes the torque and speed depending on the loads on the blade assembly.

Blades/Saw

NG-9/2400 : 9 OR 10 Blades
Ng5/3000 : 5 Blades

Main Motor

This motor provides rotary motion to the Housing via a set of belts and pulleys.

Center Box

The whole blade assembly is mounted on this box. It provides horizontals movement to the blade assembly.

Column Assembly

Column assembly consisting of two chrome platted pipes on the each side (4 pipes in total). Column assembly provides vertical linear motion to the beam. Chrome plated columns also ensures the high-precision, high-rigidity, energy-saving, high-speed motion with long service life.

SPECIFICATIONS

NG-9/2400

TYPE		KMT NG-9/2400
NUMBER OF BLADES		9
USEFUL CUTTING SIZE	LENGTH (mm)	3300
	HEIGHT(mm)	1000
	WIDTH (mm)	2000
MOTORS POWER	MAIN (HP)	75 HP 1400 RPM
	BEAM (UP/DOWN)	5 HP 1440 RPM
	HYDRAULIC	3 HP
	BEAM LT	2 HP
LENGTH OF BEAM		8.5 (m)
CYCLE PER MINUTE		325
WEIGHT OF THE MACHINE		17000 kg. (Approx.)
DIMENSIONS OF TROLLEY		2100 X 3050
The technical data (dimensions and weight) provided in the above table are not binding. We reserve the right to introduce and bring alterations without any prior notice to the customer.

NG-5/3000

KMT MULTI BLOCK CUTTER
TYPE		KMT NG 5/3000
NUMBER OF BLADES		5
USEFUL CUTTING SIZE	LENGTH (mm)	3300
	HEIGHT(mm)	1300
	WIDTH (mm)	2000
MOTORS POWER	MAIN (HP)	75 HP 1400 RPM
	BEAM (UP/DOWN)	5 HP 1440 RPM
	TO & FRO MOTION	5 HP
	BEAM LT	2 HP
LENGTH OF BEAM		9.5 (m)
CYCLE PER MINUTE		325
WEIGHT OF THE MACHINE		19000 kg. (Approx.)
DIMENSIONS OF TROLLEY (mm)		2100 X 3050
The technical data (dimensions and weight) provided in the above table are not binding. We reserve the right to introduce and bring alterations without any prior notice to the customer.
